Agent Two
Panel mount IoT Node
Industrial IoT Node featured with ESP32-WROOM SoC, built into a panel mount device, for applications which requires tiny display.
Front mount USB port provides easy access to programming and a button connected to GPIO provides facility for user inputs.
Can be ordered with 0.96 OLED display or RGB pixel LED.
Processors
ESP32-WROOM32
Dual Core 32bit 160-Mhz CPU
520 Kbytes SRAM / 4 Mb Flash
Two timer groups, including 2 x 64-bit timers and 1 x main
watchdog in each group
Communication
Features
Operating system and Software
- Arduino (C++)
- MicroPyton
- ESP-IDF (Espressif IoT Development Framework)
- Zephyr Project
- Mongoose OS
AP01-BC1
4X
24V
Sink/Source Digital Inputs
4 X
0-10V Analog Inputs
1 X
RS-485
AP01-BC2
4X
24V
Sink/Source Digital Inputs
4 X
0 -20 mA Analog Inputs
1 X
RS-485
AP01-BA1
4X
24V
Sink/Source Digital Inputs
1 X
5A Relay NO
AP01-BA2
4X
24V
Sink/Source Digital Inputs
1 X
RS-485
Applications
- Machine Monitoring
- Low power sensor node
- Simple process controller
- Datalogger
- WiFi – NB-IoT Bridge
- Modbus Gateway
- MQTT Gateway
