Agent 1 | Industrial IoT Node
Agent One
Industrial IoT Node
Industrial IoT Node featured with multiple processor and communication options. It can be used in various applicaitons from Industrial IoT to a simple data logger. It can be ordered with ESP32-WROVER-B or with Ultra low power STM32L151xE.
Industrial ESP32 Node supports LoRa, NB-IoT and WiFi communication, making it the most versatile controller on the market.
Agent 1 industrial node is a programmable controller, it has built in USB communication for programming as well as diagnosis. Moreover it has user programmable RGB led and 4 individual indicators for digital inputs.
We have embedded lots of useful features to make things easy for you.
Discover yourself.
Processors
ESP32-WROVER
Dual Core 32bit 160-Mhz CPU
520 Kbytes SRAM / 4 Mb Flash
Two timer groups, including 2 x 64-bit timers and 1 x main
watchdog in each group
STM32L151xE
Ultra Low Power
ARM® Cortex®-M3 32-bit CPU
512KB Flash
80KB SRAM / 16KB EEPROM
Communication
Features
Pixel RGB Led Indicator
SMA External Antenna
Ultra Low Energy Battery Powered Applications
Agent One Industrial Controllers are offered for low power applications as well, devices controlled by STM32L series micro-controller are used for Ultra Low Power applications where you need to run the devices from batteries for years. Agent One BT range is specially designed with transistor outputs to power down external sensors when the device goes to sleep.
Operating system and Software
- Arduino (C++)
- MicroPyton
- ESP-IDF (Espressif IoT Development Framework)
- Zephyr Project
- Mongoose OS
Models
AT01-BM1
3X
24V
Sink/Source Digital Inputs
3 X
0-10V Analog Inputs
1 X
RS-485
AT01-BM2
3X
24V
Sink/Source Digital Inputs
3 X
0 -20 mA Analog Inputs
1 X
RS-485
AT01-BT1
3X
24V
Sink/Source Digital Inputs
3 X
0 - 10V Analog Inputs
2 X
Open collector Transistor
AT01-BT2
3X
24V
Sink/Source Digital Inputs
3 X
0 -20 mA Analog Inputs
2 X
Open collector Transistor
AT01-BT3
3X
24V
Sink/Source Digital Inputs
2 X
Thermocouple Inputs
2 X
Open collector Transistor
AT01-BT5
3X
24V
Sink/Source Digital Inputs
3 X
0 - 10V Analog Inputs
1 X
5A Relay
AT01-BT6
3X
24V
Sink/Source Digital Inputs
3 X
0 -20 mA Analog Inputs
1 X
5A Relay
Applications
- Machine Monitoring
- Low power sensor node
- Simple process controller
- Datalogger
- WiFi – NB-IoT Bridge
- Modbus Gateway
- MQTT Gateway
